product model

CPF1018

screen

size

10.1 inches

resolution ratio

1280*800

luminance

300cd/㎡

touch control

multi point capacitance touch screen

surface

pigment

White, Black

cheek

White, Space Gray, Blue, Black, Pink, Wood Grain Water Transfer, Solid Wood

Basic specifications

operating system

Android 11

App

Zicalstar

processor

High performance and low power consumption quad-core ARM Cortex-A53 processor

memorizer

1G DDR+16G EMMC

device power supply

DC12V/0.8A (1.8 meters long, with an outer diameter of 3.5 mm and AWG 22W)

Device power consumption

10 Max

relative humidity

0%-90% (in the absence of condensed water droplets)

working temperature

0°C～45°C

storage temperature

-20°C～70°C

service environment

indoor

Device size

261.5mm*180.3mm*23.9mm

joggle

Reset key *1

Type-C *1

DC power port *1

Supports micro TF card slot (optional), up to 128GB

loudspeaker

8 euros for 10,000 units *2

microphone

MIC *2 optional

essential parameter

WIFI

2.4G/5G supports IEEE 802.11b/g/n

PDA

Supports Bluetooth 2.1/3.0/4.0/4.2

light sensation

0.01 to 157K lux, light-transmitting but not hole-porous (optional)

Human body infrared sensing

Recognition range up to 4.5 meters, with optional panel openings

Package parameters

weight

TBD

size

295*224*73mm
